High-efficiency dispersion, cut, refinement, smash, emulsification, mixing, homogenization, high purity solution
Very simple maintenance, no special tools required, no professionals required

Max flow: 50m3/h

Max power: 160KW

Max temperature: -20℃~140℃

Material: 304 /316L, 1.431/1.4404, ASME BPE 316L, 1.4435 NB2 Fe≤0.5% Dual-phase steel 2205, Hastelloy alloy C276

Surface treatment: ≤ Ra0.8μm，≤ Ra0.6μm，≤ Ra0.4μm

Mechanical seal: Single and double mechanical seals

Mechanical seal combination: See configuration table

Inlet/outlet connection: Thread, clamp, flange, Aseptic flange

Certification: 3-A-02-12(N.O.1579); MD/06/42-EC (N.O.70521616101-00); FDA 177.2600; USP CLASS-II; EG/VO1935/2004
