Solution for high efficiency, low noise, simple and economical maintenance, high pruity

Flow: 0.5m3/h-120m3/h

Head: 70M

Temperature: -20℃~140℃ From -20℃ to 140℃

Power: 0.55KW-30KW

Material: 304 /316L, 1.4301/1.4404, ASME BPE 316L, 1.4435 BN2 Fe≤0.5% Dual-phase steel 2205, Hastelloy alloy C276

Surface treatment: ≤ Ra0.8μm, ≤ Ra0.6μm, EP≤ Ra0.4μm

Mechanical seal: Single mechanical seal, double mechanical seal, details see configuration table

Inlet/Outlet Connection: Thread, Clamp, Flange, Aseptic flange

Certification: 3-A-02-12(N.O.1579); MD/06/42-EC(N.O.70521616101-00);FDA 177.2600; USP CLASS-II; EG/VO1935/2004
